Walk-In Fume Hoods FHW-1000 Series
Walk-In Fume Hoods FHW-1000 Series

The FHW-1000 series Walk-in fume hood supply exhaust system for large laboratory instruments and equipment. Meanwhile, operators can walk into the fume hood to operate the equipment conveniently and directly.

  • Operators are available to walk into the fume hood to operator if needed.
  • Large room exhaust system, suitable for large laboratory instrum...
  • Full Description
  • Specifications

The FHW-1000 series Walk-in fume hood supply exhaust system for large laboratory instruments and equipment. Meanwhile, operators can walk into the fume hood to operate the equipment conveniently and directly.

  • Operators are available to walk into the fume hood to operator if needed.
  • Large room exhaust system, suitable for large laboratory instruments and equipment.

FHW-1000 is widely used in bellow areas:

  • Hospitals & Pharmaceutical
  • R & D Centres
  • Education Institutions
  • Petroleum & Petrochemical Plants
  • Other Industrial Projects

Water Sink

Water Sink



Water & Gas Remote Control Valve

Water & Gas Remote Control Valve



Water & Gas Tap

Water & Gas Tap

Model

FHW-1000

FHW-1200

FHW-1500

External Size (W*D*H) mm

1200*850*2200mm

1500*850*2200mm

1800*850*2200mm

Internal Size (W*D*H) mm

1000*650*1500mm

1300*650*1500mm

1600*650*1500mm

Internal Size (W*D*H) mm

975

1267

1560

Max Opening (mm)

1150mm

Exhaust Airflow Volume

1150m3/h

1500m3/h

1850m3/h

Inflow Air Velocity

≥0.4m/s

Noise

62dB

Vibration

XYZ direct ≤4μm

Illumination

≥800Lux

Fluorescent Lamp

21W*2

28W*2

40W*2

Power Supply

220V±10%, 60/50Hz；110V±10%, 60Hz

Consumption

400W

500W

500W

Front Window

Manual, Toughened glass., Anti UV

Material



Exterior

1.2mm cold-rolled steel with bacteria powder coating.

Interior

High grade melamine board with good acid and alkali resistance function

Standard Accessories



Blower( External) ,Fluorescent lamp, Water tap, Gas tap, PP cup sink, Remote control water valve, Remote control gas valve, Waterproof sockets * 4, ?300mm PVC Duct

 Waterproof Sockets

Total load of 4 waterproof sockets: ≤500W

Package Dimensions (W*D*H) mm

1410*1050*2430mm

1710*1050*2430mm

2010*1050*2430mm

Exhaust Blower

970*810*580mm

970*810*580mm

970*810*580mm

Electrical Requirements

110V

220V

110V

220V

110V

220V

Catalogue No.













  • Request Information

    • Request Information

    * Required fields

      Catalogue No. Image Product Detail Availability Price
    (Excludes VAT)
    		FHW-1000

    Fume Hood FHD-1700 is used to protect lab environment and operator during general chemical applications. It actively protects operator from...

    2 - 3 weeks

    $3,200.00

    Add to Cart
    		FHW-1200

    Fume Hood FHW-1200 is used to protect lab environment and operator during general chemical applications. It actively protects operator from...

    2 - 3 weeks

    $3,400.00

    Add to Cart
    		FHW-1500

    Fume Hood FHW-1500 is used to protect lab environment and operator during general chemical applications. It actively protects operator from...

    2 - 3 weeks

    $4,000.00

    Add to Cart
