Circulating Water Bath WS Series

Circulating Water Bath WS Series feature with PT-100Ω sensor along with the external circulating pump. Best suited for choice for research work requiring a basic, ease-to-use quality water bath.

Gable cover included as optional along with heating circulator. The WS range consists of two models-10 L and 20 L. A cost-effective range of multi-purpo...

  • Full Description
  • Specifications

Circulating Water Bath WS Series feature with PT-100Ω sensor along with the external circulating pump. Best suited for choice for research work requiring a basic, ease-to-use quality water bath.

Gable cover included as optional along with heating circulator. The WS range consists of two models-10 L and 20 L. A cost-effective range of multi-purpose baths for ambient temperature applications, and provide overheat protection.

Digital PID control for rapid and fast heat-up, precision control during the temperature range.

  • Tank is using seamless stainless steel and the outside body is powder painting
  • Screen-touch panel, micro-computer PID digital display
  • Overheat protector
  • The water bath with circulator using electric heat tube to unify temperature inside
  • Add exterior circulator as require
  • The sensor is PT-100Ω
  • Gable cover (AC-100) sold separately for your option.
  • Heater of stainless steel
  • External Circulating Pump is Available
  • Heating circulator sold separately for your option
  • Optional Water level protector
  • Optional Timer



Model

WS-100

WS-200

Capacity

10 L

20 L

Range

Ambient +5℃~100℃

Accuracy

±0.1℃

Control

PID Control

Display

LED

Inside Dimension

295 x 235 x 150 mm

495 x 295 x 150 mm

Outside Dimension

340 x 280 x 310 mm

540 x 340 x 310 mm

Net Weight

7 kg

9 kg

Electrical Requirement



110V/60Hz

2220V/50Hz

110V/60Hz

2220V/50Hz

Catalogue No.

1051005-01

1051005-02

1051010-01

1051010-02

  • Request Information
  • Request Information

    * Required fields

      Catalogue No. Image Product Detail Availability Price
    (Excludes VAT)
    WS-100

    Tank is using seamless stainless steel and outside body is powder painting Screen-touch panel, micro-computer PID digital display Overheat...

    2 - 3 Weeks

    Price On Request

    WS-200

    Tank is using seamless stainless steel and outside body is powder painting Screen-touch panel, micro-computer PID digital display Overheat...

    2 - 4 Weeks

    $595.00
