Model

IDPP-570-01

IDPP-570-02

IDPP-570-03

IDPP-570-03

Flow rate (ml/min/channel)

0.07 to 570

1.7 to 435

0.000166 to 49(working speed ≤150 rpm)

0.000185 to 65(working speed ≤150 rpm)

Pump Head

I-955412

I-655300

IP1-IP12

IP1-IP12

Number of Rollers

-

-

10

6

Tubing Size (mm)

13, 14, 19, 16, 25, 17, 18

15, 24

Inner Diameter: 0.13 to 3.17 mm Wall thickness: 0.8 to 1

 Inner Diameter: 0.13 to 3.17 mm Wall thickness: 0.8 to 1

Speed Range

1 to 600 rpm

Speed Resolution

0.01 rpm

Accuracy

< ± 0.5%

Materials

ABS (Plastic shell + UV spray coating)

Operating Temperature

0 to 40 ℃

Motor

Stepper type

Colour

White, Black

Display

4.3-inch Industrial grade true colour

Dispensing Volume Range

0.01 to 9999.99 ml

Dispensing Volume Resolution

0.01 ml

Dispensing Time

0.1 to 9999.99 s

Pause Time

0.1 to 9999.99 s

Time Resolution

0.01 s

IP-Rate

IP31

CE certification

Yes

SGS certification

Yes

Keypad lifetime

300,000 times

Start/Stop Direction Signal

Passive switch signal: foot pedal
Active switch signal: 5V, 12V and 24V(Option)

Copy Number

1 to 9999 numbers, setting 0 means unlimited

Buck suction Angle

0 to 360°

Outlet Pressure

0.1Mpa(0.8 to 1.0 mm wall thickness tubing)
0.1 to 0.27 MPa(1.6 to 2.4 mm wall thickness tubing)

Communication

RS232, RS485 support MODBUS (RTU mode)

Power Consumption

< 50 W

Humidity

< 80%

Dimension

210.6×152×236.9 mm

Drive Weight

4.40 kg

Electrical Requirement

110V/60Hz

220V/50Hz

110V/60Hz

220V/50Hz

110V/60Hz

220V/50Hz

110V/60Hz

220V/50Hz

Catalogue No.

490450501

490450502

490451001

490451002

490451501

490451502

 490452001

490452002
